Alveo U30 Data Center Accelerator Card

Overview

Product Description

The Alveo U30 media accelerator card provides the industry’s highest channel density, lowest cost per channel, and lowest power consumption for live video streaming workloads. When coupled with Xilinx’s Video Software Developers Kit (SDK) the solution provides a production-ready platform for live streaming providers to benefit from Xilinx hardware acceleration with standards-based FFmpeg, GStreamer and APIs.

The U30 is available for live video transcoding in the cloud over Amazon EC2 VT1 instances or as a preconfigured appliance for on-premises deployment from our partners.

Features

  • Small footprint – half-height, half-length
  • Low power ~18-25W typical
  • High density media processing: 112 x 1080p30 transcodes in real-time on a single appliance populated with 7 x Alveo U30 accelerators
  • HEVC (H.265), H.264 (AVC) & Adaptive Bit Rate (ABR) Scaling
  • Supports video resolutions from 128x128 to 3840x2160
  • Simultaneous decoding, scaling and encoding of up to 46 streams with max aggregated bandwidth of 2X4Kp60 per card
  • Faster-than-Real-Time (FTRT) feature enables a 60 minute 1080p60 quality video to be transcoded in 20 minutes on a single U30 accelerator
  • Xilinx Resource Manager (XRM) enables multiple video processing jobs to run across multiple Alveo U30 cards for seamless workload scaling Seamless FFmpeg, GStreamer and API integration

Key Features & Benefits

Built for Performance & Efficiency

  • A single U30 card can deliver two simultaneous 4kp60 or 32x 720p transcodes
  • H.264 & H.265 support with 8/10bit HDR capability
  • Highest density and better compression efficiency over ASIC or GPU solutions

Adaptable with Ease of Integration

  • Adaptive Bit Rate Video Transcoding
  • FFmpeg Video Support: Free and open-source project used by developers and software workflows
  • Simple API based on industry standard FFmpeg framework





Accessible - Cloud <-> On-Premises Mobility

  • Built for scale out architectures for deployment solutions on the cloud or on-premises interchangeably



Specifications

Alveo U30 Accelerator Card Specifications

  Feature Alveo U301
Dimensions Width Single Slot
Form Factor, Passive Form Factor, Active Half Height, ½ Length
Logic Resources2 Look-Up Tables 460K
Registers 920K
DSP Slices 3,456
Video support Video Codec Unit (VCU) Hardened
Codec H.264 and H.265
Video Transcodes per Card 2 x 4kp60, 8 x 1080p60,16 x 1080p30, 32 x 720p30
DRAM Memory DDR Format 2 x 4GB 72b DDR4
DDR Total Capacity 8GB
DDR Max Data Rate 2400MT/s
DDR Total Bandwidth 38GB/s
Internal SRAM Total Capacity 11MB
Total Bandwidth 10TB/s
Interfaces PCI Express® Gen3 x8, 2 x Gen3 x43
Network Interface
Power and Thermal Thermal Cooling Passive
Typical Power 18-25W typical*
Maximum Power 75W
Tool Support Vivado® Design Suite No
FFmpeg with Xilinx Video Plugins Yes
Vitis™ Developer Environment No
Solutions Solutions & Libraries Video Transcoding Solutions

Notes

  1. The Alveo U30 Media Accelerator Card is designed for use in Xilinx real-time evaluation servers or turn-key high-density video transcoding appliances offered by Xilinx VARs.
  2. Logic resources shown are without platform usage. User does not have access to these resources on the Alveo U30 card.
  3. Servers need to support bifurcation for users to take advantage of both Zynq® UltraScale+™ devices on the Alveo U30 card.
Documentation
Default Default Title Document Type Date
Software Developers Kit

Xilinx Video Software Developers Kit (SDK)

Accelerate your streaming workflows with our turnkey software developers kit (SDK).  Access the tools, APIs, and high-level FFmpeg frameworks, GStreamer, or your own proprietary framework via C/C++ APIs and get up and running in just one day.

The U30 Video SDK is a complete software stack allowing users to seamlessly leverage the hardware accelerated features of Alveo U30 cards for on-premises or cloud deployments. It includes the following elements:

  • A pre-compiled version of FFmpeg integrates key video transcoding plug-ins, enabling simple hardware offloading of compute-intensive workloads using the FFmpeg command line interface.
  • Xilinx Media Accelerator (XMA) library: a host interface meant to simplify the development of applications that manage and control video accelerators, such as decoders, scalers, filters, and encoders. It integrates the Alveo U30 transcoding capabilities into the FFmpeg  framework.
  • Xilinx Resource Manager (XRM): manages and allocates all the hardware accelerated  features.  XRM  enables  multiple video processing jobs to run across multiple Alveo U30 cards for seamless workload scaling
  • Xilinx Runtime library (XRT): manages communication between the application code and the accelerated-kernels deployed on the Xilinx Alveo accelerator card
  • A suite  of  card  management  tools  (XCLBIN)  perform  actions  such  as  programming,  resetting,  or  querying the status of U30 cards

Full documentation including installation guide, tutorials and demo videos available on GitHub

Cloud Transcoding

Amazon EC2 VT1 Instances

Amazon EC2 VT1 instances are designed to accelerate real time video transcoding and deliver low cost transcoding for live video streams.

They can deliver up to 30% lower cost per stream compared to Amazon EC2 G4dn GPU-based instances and up to 60% lower cost per stream compared to Amazon EC2 C5 CPU-based instances for transcoding live video streams.

  • 30% Lower cost vs. GPU
  • Support for up to 64 1080p60 streams in real time
  • Support for up to 4K UHD at 60fps
25-icon

Gbps of high speed networking and storage

30-percent-icon

Lower cost vs GPU

64-icon

Simultaneous 1080p60 streams in real time

4k-icon

Support for up to 4K UHD at 60fps
