Versal Premium Series

The Highest Bandwidth and Compute Density
On an Adaptable Platform
From Network to Cloud

Product Advantages

Breakthrough Integration of Networked IP on a Power-Optimized Adaptable Platform

Versal Premium

Key Features


Blue fiber optic cables for 112G PAM4 Transceivers

112G PAM4 Transceivers

800G Networks and Beyond

The Versal® Premium series’ 112G PAM4 transceivers are central to enabling power-optimized, 800G network systems. The Versal Premium ACAP features a broad selection of 32G, 58G, and 112G transceivers on the same device, allowing vendors to scale mainstream 100G systems, ramp 400G deployment, and position themselves for 800G and beyond.

Digital crypto padlock

400G High-Speed Crypto Engines

Line Rate Encryption for Secure Networks

The Versal Premium ACAP delivers 1.6Tb/s of line rate encryption throughput, making it an ideal platform for secure networks. It features the world’s only hardened 400G channelized High-Speed Crypto (HSC) Engines in an adaptable platform. The HSC Engine supports the AES-GCM encryption/decryption, MACsec, and IPsec for multi-layered security.


Multirate Ethernet Cores with FEC

Single Platform for 10G to 800G

The dedicated connectivity IP enables secure multi-terabit Ethernet with support for many data rates and protocols. The mix of 100G and 600G Ethernet cores delivers up to 5Tb/s of throughput and allows scalability from the access network to metro to core, all on a single platform.



600G Interlaken with FEC

Scalable Chip-to-Chip Interconnect

Integrated Interlaken cores in the device support up to 600Gb/s with built-in flow control for reliable, high-bandwidth data transmission. With integrated RS-FEC for power-optimized error correction, Versal Premium devices support scalable chip-to-chip interconnect while minimizing the I/O and power overhead for networking systems.


PCIe Gen5 with DMA & CCIX, CXL

Optimal CPU-to-Accelerator Communication

PCIe® Gen5 accelerates server CPU-to-accelerator communication for next-generation compute applications, while the hardened DMA engines with programmable NoC deliver scalable and turn-key virtualization for workload provisioning and deployment. The CCIX/CXL sub-blocks enable (a)symmetric communication for diverse cloud topologies.


Programmable Network on Chip

Guaranteed QoS and Power Efficiency

The programmable network on chip (NoC) provides an optimized multi-terabit interconnect between the different compute engines and integrated IP blocks in the Versal ACAP, simplifying timing closure and saving logic resources. The NoC compiler provides a streamlined programming experience while allowing users to manage latency and QoS for critical datapaths.



Scalar Engines

Three scalar processor types are available for diverse application needs. The application processing unit is ideal for complex applications supported by an OS, and the real-time processing unit is ideal for latency-sensitive applications. A separate platform management controller manages system boot, security, and debug.

Adaptable Engines

Programmable logic enables the development of custom computational blocks for differentiation, future-proofing, and ever-changing algorithms. Loaded with a wide variety of memory elements and tightly coupled with programmable I/O, the Adaptable Engines allow users to create powerful accelerators for any application.

Intelligent Engines

Enhanced DSP Engines provide support for a variety of operations and data types, including single and half-precision floating-point and complex 18x18 operations. With backward compatibility to UltraScale+™ device designs, users can either leverage existing libraries or update their designs for the maximum compute performance.


Find Out More



Solving a broad range of industry-specific problems with performance and flexibility


Data Center Network Acceleration

Metro/Core Transport Networks

Due to fast-growing bandwidth demands for 5G wireless, xHaul, PON, and cable access, there is tremendous pressure on the metro/transport networks to aggregate and intelligently process network traffic. Versal® Premium series provide 112G PAM4 transceivers with dedicated connectivity IP such as 600G channelized multirate Ethernet and integrated 600G Interlaken with FEC to enable thermally efficient designs in complex metro/core transport networks.

With double the compute density of traditional hardware programmable devices, Versal Premium enables hardware differentiation, adaptability to evolving standards, and the ability to infuse AI/ML for tomorrow’s autonomous and intelligent networks.

Data Center Interconnect

As data centers scale, data center interconnect (DCI) technologies must evolve to enable high capacity, scalability, and power efficiency. Versal Premium series allows service providers to deploy flexible transport technology by providing scalable transceivers up to 112G, up to 5Tb/s of ethernet throughput, and 1.6Tb/s of line-rate encryption for fast and secure connectivity between data centers.

Data Center Network Acceleration

Data Center Network Acceleration

Scalable Acceleration in the Data Center

As a heterogeneous platform, Versal Premium features the world’s highest compute density for adaptable cloud acceleration for a breadth of workloads, including genomics, video transcoding, search, and machine learning.

Dynamic function exchange (DFx) allows users to swap compute kernels in milliseconds to provision accelerators for the most efficient use of cloud infrastructure. With massive on-chip memory capacity and bandwidth and double the compute density of currently deployed FPGA accelerators, Versal Premium offers superior compute and streamlined orchestration.

Built from the ground up to seamlessly integrate with cloud infrastructure, Versal Premium features an integrated shell that ensures host server and system memory communication is available at boot, allowing accelerator designers to spend less time on connectivity and more time on differentiation.


Test Equipment

To pioneer network technologies at 800G and beyond, vendors need to leverage bleeding-edge communication test equipment to ensure interoperability and robust network traffic management. Versal Premium series provides 112G PAM4 transceivers with integrated KP4 FEC for emerging protocols as well as interoperability with optics and backplanes. Dedicated channelized multirate Ethernet cores with aggregate throughput of 3.2Tb/s feature individually accessible MAC, PCS, and FEC blocks alongside programmable logic resources for custom error injection and statistical analysis.

Co-optimized with Vivado Design Suite, Versal Premium can implement the most complex test logic for automated test, data-flow control, tracking, and reporting for L2-L3 (800G), SSD, and PCIe protocol test equipment.


Data Center Network Acceleration
Product Table

Versal® Premium Series Features Overview

Scalar Engines Features

  VP1102 VP1202 VP1402 VP1502 VP1552 VP1702 VP1802
Application Processing Unit Dual-core Arm® Cortex® A72, 48KB/32KB L1 Cache w/ parity & ECC; 1MB L2 Cache w/ ECC
Real-Time Processing Unit Dual-core Arm Cortex R5F, 32KB/32KB L1 Cache, and 256KB TCM w/ECC
Memory 256KB On Chip Memory w/ECC
Connectivity Ethernet (x2); UART (x2); CAN FD (x2); USB 2.0 (x1); SPI (x2); I2C (x2)

Intelligent Engines Features

  VP1102 VP1202 VP1402 VP1502 VP1552 VP1702 VP1802
DSP Engines 1,904 3,984 2,672 7,440 7,392 10,896 14,352

Adaptable Engines Features

  VP1102 VP1202 VP1402 VP1502 VP1552 VP1702 VP1802
System Logic Cells (K) 1,575 1,969 2,233 3,763 3,837 5,558 7,352
LUTs 719,872 900,224 1,020,928 1,720,448 1,753,448 2,540,672 3,360,896

Foundational Platform Features

  VP1102 VP1202 VP1402 VP1502 VP1552 VP1702 VP1802
GTYP Transceivers (32.75Gb/s) 8 28 8 28 68 28 28
GTM Transceivers (58G (112G)) 64 (32) 20 (10) 96 (48) 60 (30) 20 (10) 88 (44) 140 (70)
CCIX & PCIe® w/DMA (CPM) - 2 x Gen5x8, CCIX - 2 x Gen5x8, CCIX 2 x Gen5x8, CCIX 2 x Gen5x8, CCIX 2 x Gen5x8, CCIX
PCI Express® with CXL 2 x Gen5x4 2 x Gen5x4 2 x Gen5x4 2 x Gen5x4 8 x Gen5x4 2 x Gen5x4 2 x Gen5x4
100G Multirate Ethernet MAC 6 2 6
4 4 6 8
600G Ethernet MAC 7 1 11 3 1 5 7
600G Interlaken 0 0 0 1 0 2 3
400G High-speed Crypto Engines 3 1 4 2 2 3 4


Versal Design Guidance and Documentation

Xilinx provides a breadth of documentation, resources, and methodologies to accelerate your development on the Versal architecture. If you’re not sure where to begin with Versal ACAPs, the Design Flow Assistant is an interactive guide to help you create a development strategy, while the Design Process Hubs are a visual and streamlined reference to all Versal documentation by design process.

Default Default Title Document Type Date
Get Started

Integrated Software and Hardware Platform for All Developers

With an inherently software programmable silicon infrastructure, the Versal® ACAP is designed from the ground up to be software-centric. The enhanced Xilinx® Vivado® Design Suite introduces a new system design methodology and development environments such as traffic analyzer, NoC compiler, data flow modeling, and more. A high-speed, unified, cohesive debug environment accelerates debug and trace across Scalar, Adaptable, and Intelligent engines.
Download Vivado Design Suite >

The Xilinx Vitis™ unified software platform provides comprehensive core development kits, libraries that use hardware-acceleration technology. The platform provides an efficient, convenient, and unified software environment from the cloud to the edge. As a proud member of the open source community, the Vitis unified software platform is entirely free and open source.
Download Vitis Unified Software Platform >

Versal Prime Series

Versal ACAP Evaluation Kits

Be the first to experience the Versal ACAP architecture, built from the ground-up to be natively software programmable. Through a host of tools, software, libraries, IP, middleware, and frameworks, the Versal ACAP enables dynamically customizable accelerated computing solutions.

While you are waiting for Versal Premium series evaluation kits, you can jump-start your application development for Versal Premium series with the VMK180.  The VMK180 supports a subset of the Versal Premium features.

Learn more about the Versal Prime series VMK180 Evaluation Kit >

Training Courses

Xilinx training and learning resources provide the practical skills and fundamental knowledge you need to be fully productive in your next development project.

Getting Started with the Xilinx Versal ACAP Platform
Designing with the Versal ACAP: Architecture and Methodology
Designing with the Versal ACAP: Programmable Network on Chip
Designing with the Versal ACAP: Power and Board Design
