Enabling Next Generation ADAS and AD Systems

Product Advantages

Automotive grade Zynq UltraScale+ MPSoC Product Advantages

The Xilinx Automotive XA Zynq® UltraScale+™ MPSoC family is qualified according to AEC-Q100 test specifications with full ISO26262 ASIL-C level certification. The product integrates a feature-rich 64-bit quad-core ARM® Cortex™-A53 and dual-core ARM Cortex-R5 based processing system (PS) and Xilinx programmable logic (PL) UltraScale architecture in a single device. This scalable solution is ideally suited for various automotive customer platforms by delivering the right performance/watt while integrating critical functional safety and security features.

Value Features
Smarter, Optimized & Most Secure Solution
  • Innovative ARM® + FPGA architecture for differentiation, analytics & control
  • Extensive OS, middleware, stacks, accelerators, and IP ecosystem
  • Multiple levels of hardware and software security
Unmatched Integration, Performance, and Power
  • Integration delivering the de facto programmable platform
  • Up to 5X system level performance per watt over Zynq-7000 SoCs
  • Architected to deliver lowest system power
Proven Productivity
  • Most flexible & scalable platform for maximum reuse and best TTM
  • Industry leading design tools, C/C++, Open CL design abstractions
  • Largest portfolio of SW & HW design tools and reference designs
Product Table

Processing System (PS)

Features All Devices
Application Processing Unit Quad-core ARM Cortex-A53 MPCore with CoreSight; NEON & Single/Double Precision Floating Point; 32KB/32KB L1 Cache, 1MB L2 Cache
Real-Time Processing Unit Dual-core ARM Cortex-R5 with CoreSight; Single/Double Precision Floating Point; 32KB/32KB L1 Cache, and TCM
Embedded and External
Memory256KB On-Chip Memory w/ECC; External DDR4; DDR3; DDR3L; LPDDR4; LPDDR3; External Quad-SPI; NAND; eMMC
General Connectivity

214 PS I/O; UART; CAN; USB 2.0; I2C; SPI; 32b GPIO; Real Time Clock; WatchDog Timers; Triple Timer Counters

High-Speed Connectivity 4 PS-GTR; PCIe Gen1/2; Serial ATA 3.1; DisplayPort 1.2a; USB 3.0; SGMII
Graphic Processing Unit ARM Mali™-400 MP2; 64KB L2 Cache

Programmable Logic (PL)

System Logic Cells (K) 103 154 192 256
Memory (Mb) 5.3 7.6 18.5 23.1
DSP Slices 240 360 728 1,248
Video Code Unit (VCU)     1 1
Maximum I/O Pins 252 252 252 252
Download PDF

Note: Some restrictions may apply. Refer to UG585, Zynq-7000 SoC Technical Reference Manual and DS188, XA Zynq-7000 SoC Overview for details.
