AMD takes our commitment to long lifecycles very seriously. We are pleased to announce that support is formally being extended for all 7 series devices until at least 2035. This includes all speed and temperature grades for Spartan™ 7, Artix™ 7, Kintex™ 7, and Virtex™ 7 FPGAs, as well as Zynq™ 7000 SoCs.

Zynq 7000 SoC Product Advantages

The Zynq™ 7000 SoC family integrates the software programmability of an Arm®-based processor with the hardware programmability of an FPGA, enabling key analytics and hardware acceleration while integrating CPU, DSP, ASSP, and mixed signal functionality on a single device. Consisting of single-core Zynq 7000S and dual-core Zynq 7000 devices, the Zynq 7000 family offers an exceptional price to performance-per-watt, fully scalable SoC platform for your unique application requirements.

Block Diagram Description

Click to enlarge

Zynq 7000S

Zynq 7000S devices feature a single-core Arm Cortex®-A9 processor mated with 28nm Artix™ 7 based programmable logic, representing a low cost entry point to the scalable Zynq 7000 platform. Available with 6.25 Gb/s transceivers and outfitted with commonly used hardened peripherals, the Zynq 7000S delivers cost-optimized system integration ideal for industrial IoT applications such as motor control and embedded vision.

Click to enlarge

Zynq 7000

Zynq 7000 devices are equipped with dual-core Arm Cortex-A9 processors integrated with 28nm Artix 7 or Kintex™ 7 based programmable logic for excellent performance-per-watt and maximum design flexibility. With up to 6.6M logic cells and offered with transceivers ranging from 6.25 Gb/s to 12.5Gb/s, Zynq 7000 devices enable highly differentiated designs for a wide range of embedded applications including multi-camera drivers assistance systems and 4K2K Ultra-HDTV.

Value Features
Smarter, Optimized, and Most Secure Solution
  • Innovative Arm® + FPGA architecture for differentiation, analytics & control
  • Extensive OS, middleware, stacks, accelerators, and IP ecosystem
  • Multiple levels of hardware and software security
Unmatched Integration, Performance, and Power
  • Integration delivering the de facto programmable platform
  • System level performance through optimized architecture
  • Architected to deliver low system power
Proven Productivity
  • Most flexible & scalable platform for maximum reuse and best TTM
  • Industry-leading design tools, C/C++, and Open CL design abstractions
  • Large portfolio of SW & HW design tools, SOMs, design kits, and reference designs
Product Table

Processing System (PS)

Features Zynq 7000S Zynq 7000
Devices Z-7007S, Z-7012S, Z-7014S Z-7010, Z-7015, Z-7020 Z-7030, Z-7035, Z-7045, Z-7100
Processor Core Single-core Arm® Cortex®-A9 MPCore™ Dual-core Arm Cortex-A9 MPCore
Maximum Frequency Up to 766 MHz Up to 866  MHz            Up to 1 GHz
External Memory Support DDR3, DDR3L, DDR2, LPDDR2
Key Peripherals USB 2.0, Gigabit Ethernet, SD/SDIO
Dedicated Peripheral Pins Up to 128 Up to 128 128

Programmable Logic

Zynq 7000S

  Z-7007S Z-7012S Z-7014S
Logic Cells (K) 23 55 65
Block RAM (Mb) 1.8 2.5 3.8
DSP Slices 60 120 170
Maximum I/O Pins 100 150 200
Maximum Transceiver Count - 4 -
Download Product Selection Guide

Zynq 7000

  Z-7010 Z-7015 Z-7020 Z-7030 Z-7035 Z-7045 Z-7100
Logic Cells (K) 28 74 85 125 275 350 444
Block RAM (Mb) 2.1 3.3 4.9 9.3 17.6 19.1 26.5
DSP Slices 80 160 220 400 900 900 2,020
Maximum I/O Pins 100 150 200 250 362 362 400
Maximum Transceiver Count - 4 - 4 16
Download Product Selection Guide
